The drilling and tapping machining center series is widely used for rapid drilling, tapping, and milling of small parts such as electronics, sanitary ware, automobiles, parts, medical equipment, etc.; it is also suitable for small molds and precision copper processing.
Max. X-axis Travel :
800mmMax. Y-axis Travel :
450mmMax. Z-axis Travel :
410mmMax Workpiece Length :
1000mmMax Workpieces Width :
450mmMax Workpieces Weight :
350KGApplication :
Precision Mold, Bathroom Products, Auto Parts, Semiconductor IndustryProcessing :
Drilling, TappingCNC Tapping Center Product Characteristics
 |
The machine bed is made of high-grade HT300 cast iron precision casting The BT30 spindle speed is 20000rpm, power of the motor is 5.5kw Equipped with 21T servo saucer tool changer, tool changer time is 1.8s Rapid displacement reaches 60/60/48, and Rigidity tapping speed is 6000rpm. The drilling and tapping machining center series is widely used for rapid drilling, tapping, and milling of small parts such as electronics, sanitary ware, automobiles and parts, medical equipment, etc.; it is also suitable for small molds and precision copper processing. |
Drilling and Tapping Structural Characteristics
①. Higher Z-axis
The effective stroke of the Z axis is 410mm, the distance between the nose of the spindle and the table surface is 150-560mm, four axes can be installed without additional raiser blocks, and the rigidity of the machine tool is not affected.
②. Large Table
Table size:1000X450mm. The larger worktable allows bigger parts processing.
Optical linear scales
Optional Heidenhain, Fagor optical linear scales with an accuracy of under ±5um.
③.Stable Base
Shared V8 base, 1020mm span, high rigidity, high precision bed.
④.Powerful Motor
Standard 20000rpm BT30 high-speed motor, power 5.5kw; optional 12000rpm for large torque motor, power 7.5kw.
Fast tool change speed
Equipped with 21T servo tool magazine, tool change time is 1.8s; X/Y axis rapid traverse at 60m/min, Z axis rapid traverse at 48m/min.
Powerful spindle
YSV800 configuration BBT40 outer diameter 150mm with higher rigidity, and short nose spindle, five bearings, coolant nozzles.
Upgrade Configuration
German Rexroth roller linear guideway, Taiwan servo tool magazine, Taiwan spindle.
Beautiful appearance
European and American style sheet metal design, beautiful and practical.
Drilling and Tapping Machining Center Parameters
| Model | YST-800 | ||
| Subject | Specifications | Units | |
| Travel | X/Y/Z axis | mm | 800/450/410 |
| Spindle Nose to Worktable | mm | 150-560 | |
| Spindle Center to Column | mm | 520 | |
| Three-Axis Guideway | Ball Linear Guideway | ||
| Worktable | Worktable Size (L*W) | mm | 1000x450 |
| Maximum Table Load | kg | 350 | |
| T-Slot | mm | 3-14x125 | |
| Spindle | Spindle Taper | type | BT-30 |
| Spindle Speed | rpm | 20000 | |
| Spindle Drive Type | DDS | ||
| Feedrate | Rapid Traverse(X/Y/Z) | m/min | 60/60/48 |
| Cutting Feedrate(X/Y/Z) | m/min | 10 | |
| Tool Changer | Automatic Tool Changer | Fast Wheel | |
| Type of Tool Shank | type | BT-30 | |
| Tool Storage Capacity | Piece | 21 | |
| Max. Tool Diameter (Adjacent) | mm | 60 | |
| Max. Tool Diameter (Empty) | mm | 80 | |
| Max. Tool Length | mm | 200 | |
| Max. Tool Weight | kg | 3.5 | |
| Tool Change Time | sec | 1.8 | |
| Motor | Spindle Motor | kw | 5.5 |
| Three-Axis Servo Motor | kw | 1.5/1.5/3.0 | |
| Accuracy | Accuracy | mm | ±0.005 |
| Repeatability | mm | ±0.003 | |
| Power Required | Power Requirement | kva | 15 |
| Air Pressure Requirement | kg/cm² | 6^8 | |
| Others | External Dimensions (L*W*H) | mm | 2300x2850x2750 |
| Gross Weight | t | 4.8 | |
|
Safety Door Automatic Lubricating System
Fully Enclosure Guard
|
Rigid Tapping
Heat Exchange for Electric Cabinet
Coolant Tank & Chip Tray
|
Dual LED Work Light
LED 3 Color Warning Light
Spindle Oil Cooler
|
Spindle Nose Air Blow
Leweling Bolits and Pads
M30Auto Off
|
|
Optical Linear Scale
Chip Conveyor System
|
Tool Breakage Probe
Oil Skimmer
|
Oil Mist Collector
Workpiece& Tool Probe
|
CTS
Rotary Table
|
